ORCA-Fusion BT Digital sCMOS camera, 高感度相機(高靈敏度相機) , 科研相機


Effective no. of pixels2304 (H) × 2304 (V)
Readout speed
100 frames/s
Readout noise
0.7 electrons
Dynamic range
21 400:1

Special sites

The life science camera section is the feature section for digital cameras fit to life science research and industry areas.

ORCA-Fusion BT advantages versus other BT sCMOS cameras

Exclusive industry leading BT sCMOS performance with trusted Hamamatsu quality and reliability

  • Extremely low readout noise
  • High QE, across a wide range of wavelengths
  • CCD-like uniformity; minimal high readout noise pixels
  • High dynamic range
  • 3 readout speeds
  • Lightsheet readout mode
  • 5.3 Megapixels
  • Both USB 3.0 and high speed CoaXPress interfaces

ORCA-Fusion BT advantages versus EM-CCD cameras

A practical and functional replacement for expensive EM-CCDs with uncompromising sensitivity, speed and versatility

  • Resolution
  • Binning versatility
  • No amplification or excess noise
  • High dynamic range
  • Large field of view


  • Wide-field fluorescence microscopy
  • Time-lapse imaging
  • Spinning disk confocal microscopy
  • Lightsheet microscopy
  • Super resolution precision localization
  • Genetically encoded voltage imaging
  • Optogenetics
  • Single molecule tracking
  • Computational imaging
  • Quantum computing

Time-lapse live cell imaging by low light excitation

Sample: H9c2, Objective lens: Apo TIRF 60XC (NA1.49), ND: 8, Interval: 15 sec

Nucleusc15440-20up Application example 1

HCS NuclearMask Stains / Exposure 20 ms


Mitochondriac15440-20up Application example 3

MitoTracker / Exposure 500 ms



Membranec15440-20up Application example 2

CellMask Plasma Membrane stains / Exposure 500 ms

Lightsheet Readout Mode [Patented]

“Lightsheet Readout Mode” is a unique and patented feature of Hamamatsu sCMOS cameras which can improve signal to noise ratios in Lightsheet microscopy.
For more information about the principle and features of Lightsheet Readout Mode, please see details from below.

What is Lightsheet Readout Mode?

Lightsheet Readout Mode

PC recommendations

With the introduction of the ORCA-Fusion BT, users are now able to stream 5 megapixel images to their computers 89 frames per second. The computer recommendations for this high data rate can be met by using the guidelines listed this PC Recommendations for ORCA-Fusion BT.


Type number C15440-20UP
Quantum efficency @550 nm: 95 %
Imaging device sCMOS
Effective no. of pixels 2304 (H) × 2304 (V)
Cell size 6.5 μm (H) × 6.5 μm (V)
Readout speed Fast scan: 89.1 frames/s (@2304 x 2304 pixels, 16 bit)
Readout noise Ultra-quiet scan: 0.7 electrons rms (Typ.)
Dynamic range 21 400:1 (Typ.)
A/D converter 16 bit, 12 bit, 8 bit


Spectral response

c15440-20up Spectral response




c15440-20up dimensional outline
